- Easy and simple to understand display.
- Supporting Wi-Fi or GSM monitoring.
- Visual power flow screen.
- Built-in 2 strings of MPP trackers.
- Smart settable 3-stage MPPT charging for optimized battery performance.
- Auxiliary load function.
- Parallel / multi-invert function grid-tied and off-grid.
Specifications
- Inputs:
- PV solar
- AC grid power
- Batteries
- Generator
- Output voltage – 220/230/240Vac
- Continuous power – 3600W
- Backup power – 3600W
- DC – 48V
- Battery charger – 90A
- Transfer time <= 10ms
- Battery charger adjustable for battery bank size and type
- Can charge Lead Acid and Li-ion batteries
- Li-ion battery charging self-adapts to BMS
- Solar Input
- Max power input – 4680W
- Max V DC input – 370V (100V~500V)
- Max current input – 2 x 11A
- MPPTs – 1
- MPPT Range – 125~425V
- Multi-core processor design and advanced MPPT control
- High reliability and response speed
- Programmable export
- Works parallel on or off-grid
- Single-phase operation
- Multiple operating modes:
- Grid-tie only
- Hybrid
- Off-grid
- Battery only
- Additional features
- AC couple – For additional PV input
- 6 stages time of use settings
- IP65
- Warranty: 5 years.
